Specs
Part#
TIRE SIZE
Rim SIZE (inch)
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
TIRE PRESSURE (kPa/psi)
MAX LOAD (kg/lbs)
TREAD DEPTH (mm/in)
16
Part#
TIRE SIZE
Rim SIZE (inch)
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
TIRE PRESSURE (kPa/psi)
MAX LOAD (kg/lbs)
TREAD DEPTH (mm/in)
6.5 -16
TA34000000
6.5 -16
6
830 / 32.68
178 / 7.01
250 /
/
/
7.5 -16
TA22260000
7.5 -16
6
878 / 34.57
206 / 8.11
300 /
/
/
20
Part#
TIRE SIZE
Rim SIZE (inch)
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
TIRE PRESSURE (kPa/psi)
MAX LOAD (kg/lbs)
TREAD DEPTH (mm/in)
8.3 -20
TA00000800
8.3 -20
6
958 / 37.72
210 / 8.27
270 /
/
/
24
Part#
TIRE SIZE
Rim SIZE (inch)
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
TIRE PRESSURE (kPa/psi)
MAX LOAD (kg/lbs)
TREAD DEPTH (mm/in)
8.3 -24
TA00000900
8.3 -24
6
1055 / 41.54
210 / 8.27
270 /
/
/
9.5 -24
TA00001000
9.5 -24
6
1140 / 44.88
249 / 9.80
240 /
/
/
11.2 -24
TA00000600
11.2 -24
6
1205 / 47.44
290 / 11.42
210 /
/
/
28
Part#
TIRE SIZE
Rim SIZE (inch)
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
TIRE PRESSURE (kPa/psi)
MAX LOAD (kg/lbs)
TREAD DEPTH (mm/in)
12.4 -28
TA00001200
12.4 -28
6
1345 / 52.95
320 / 12.60
200 /
/
/
32
Part#
TIRE SIZE
Rim SIZE (inch)
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
TIRE PRESSURE (kPa/psi)
MAX LOAD (kg/lbs)
TREAD DEPTH (mm/in)
11 -32
TA00001100
11 -32
6
1460 / 57.48
310 / 12.20
160 /
/
/
