TIRE SIZE
LOAD RANGE
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
MAX PRESSURE (kPa/psi)
MAX LOAD Single/Double (lbs)
RIM WIDTH (inch)
TT/TL
TREAD DEAPTH
5.00 -12
5.00 -12
D
8PR
568 / 22.36
143 / 5.63
400 / 58
1075 / 1020
3.50
4.50 -12
4.50 -12
D
8PR
545 / 21.46
127 / 5.00
400 / 58
910 / 880
3.00
TIRE SIZE
LOAD RANGE
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
MAX PRESSURE (kPa/psi)
MAX LOAD Single/Double (lbs)
RIM WIDTH (inch)
TT/TL
TREAD DEAPTH
5.50 -13
5.50 -13
D
8PR
620 / 24.41
160 / 6.30
420 / 61
1235 / 1100
4.00
6.00 -13
6.00 -13
D
8PR
653 / 25.71
170 / 6.69
420 / 61
1435 / 1280
4.50
TIRE SIZE
LOAD RANGE
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
MAX PRESSURE (kPa/psi)
MAX LOAD Single/Double (lbs)
RIM WIDTH (inch)
TT/TL
TREAD DEAPTH
6.00 -14
6.00 -14
D
8PR
676 / 26.61
170 / 6.69
420 / 61
1520 / 1320
4.50
TIRE SIZE
LOAD RANGE
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
MAX PRESSURE (kPa/psi)
MAX LOAD Single/Double (lbs)
RIM WIDTH (inch)
TT/TL
TREAD DEAPTH
6.00 -15
6.00 -15
E
10PR
708 / 27.87
170 / 6.69
530 / 77
1820 / 1610
4.50
7.00 -15
7.00 -15
F
12PR
747 / 29.41
199 / 7.83
630 / 91
2535 / 2270
5.50
7.50 -15
7.50 -15
G
14PR
774 / 30.47
207 / 8.15
650 / 94
3195 / 3030
6.00
TIRE SIZE
LOAD RANGE
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
MAX PRESSURE (kPa/psi)
MAX LOAD Single/Double (lbs)
RIM WIDTH (inch)
TT/TL
TREAD DEAPTH
7.00 -16
7.00 -16
F
12PR
775 / 30.51
200 / 7.87
630 / 91
2680 / 2335
5.50
9.00 -16
9.00 -16
H
16PR
890 / 35.04
250 / 9.84
730 / 106
4675 / 4080
6.50
8.25 -16
8.25 -16
G
14PR
855 / 33.66
232 / 9.13
630 / 91
3750 / 3305
6.50
7.50 -16
7.50 -16
G
14PR
802 / 31.57
211 / 8.31
730 / 106
3305 / 2910
6.00
7.50 -16
7.50 -16
F
12PR
805 / 31.69
211 / 8.31
630 / 91
3085 / 2755
6.00
7.00 -16
7.00 -16
G
14PR
772 / 30.39
200 / 7.87
730 / 106
2910 / 2600
5.50
7.00 -16
7.00 -16
E
10PR
775 / 30.51
200 / 7.87
530 / 77
2405 / 2095
5.50
6.50 -16
6.50 -16
E
10PR
747 / 29.41
185 / 7.28
530 / 77
2150 / 1930
5.50
TIRE SIZE
LOAD RANGE
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
MAX PRESSURE (kPa/psi)
MAX LOAD Single/Double (lbs)
RIM WIDTH (inch)
TT/TL
TREAD DEAPTH
8.25 -20
8.25 -20
G
14PR
975 / 38.39
235 / 9.25
810 / 117
4940 / 4300
6.50
9.00 -20
9.00 -20
H
16PR
1020 / 40.16
259 / 10.20
880 / 127
6390 / 5510
7.00
10.00 -20
10.00 -20
H
16PR
1058 / 41.65
280 / 11.02
810 / 117
6610 / 5840
7.50
11.00 -20
11.00 -20
H
16PR
1090 / 42.91
298 / 11.73
790 / 115
7390 / 6395
8.00
12.00 -20
12.00 -20
J
18PR
1134 / 44.65
318 / 12.52
810 / 117
8270 / 7390
8.50
