TIRE SIZE
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
MAX PRESSURE 25km/hr (kPa/psi)
MAX LOAD 25km/hr (kg/lbs)
RIM WIDTH (inch)
TREAD DEPTH (mm/in)
5.00-8
5.00-8
10
470 / 18.50
137 / 5.39
1000 / 145
1150 / 2535
3.50D
/
18x7-8
18x7-8
14
467 / 18.39
173 / 6.81
970 / 140
1505 / 3320
4.33R
/
TIRE SIZE
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
MAX PRESSURE 25km/hr (kPa/psi)
MAX LOAD 25km/hr (kg/lbs)
RIM WIDTH (inch)
TREAD DEPTH (mm/in)
6.00-9
6.00-9
10
545 / 21.46
160 / 6.30
860 / 125
1505 / 3320
4.00E
/
21X8-9
21X8-9
14
549 / 21.61
206 / 8.11
1000 / 145
2040 / 4495
6.00E
/
TIRE SIZE
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
MAX PRESSURE 25km/hr (kPa/psi)
MAX LOAD 25km/hr (kg/lbs)
RIM WIDTH (inch)
TREAD DEPTH (mm/in)
23X9-10
23X9-10
14
610 / 24.02
230 / 9.06
900 / 130
2585 / 5700
6.50F
/
6.50-10
6.50-10
10
597 / 23.50
176 / 6.93
790 / 115
1655 / 3650
5.00F
/
6.50-10
6.50-10
12
595 / 23.43
182 / 7.17
1000 / 145
1895 / 4180
5.00F
/
TIRE SIZE
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
MAX PRESSURE 25km/hr (kPa/psi)
MAX LOAD 25km/hr (kg/lbs)
RIM WIDTH (inch)
TREAD DEPTH (mm/in)
7.00-12
7.00-12
12
683 / 26.89
189 / 7.44
860 / 125
2375 / 5235
5.00S
/
TIRE SIZE
PLY RATING
OVERALL DIAMETER (mm/in)
OVERALL WIDTH (mm/in)
MAX PRESSURE 25km/hr (kPa/psi)
MAX LOAD 25km/hr (kg/lbs)
RIM WIDTH (inch)
TREAD DEPTH (mm/in)
8.25-15
8.25-15
14
840 / 33.07
240 / 9.45
830 / 120
3775 / 8320
6.50
/
